AB-771T Wide Band Antenna

AB-771T Antenna

AB-771T Antenna

Sorry - this product is no longer available

Wide Band Antenna for use with large area assistive listening systems.

SKU: SS/14002

Please call us for a quote

Specification:

Carrier frequency range 640 ~ 865 MHz

Antenna connector TNC female connector

OIP3 +40 dBm

Gain +12 dB

Output max power +27 dBm (0.5 W)

Impedance 50 Ohms

Power requirements 115V or 230V AC adaptor 12V DC, 500mA

Dimensions (D x W x H) 205 x 215 x 44 (mm)

Weight 1.2 Kg

Overview
Contact Us

Specification:

Carrier frequency range 640 ~ 865 MHz

Antenna connector TNC female connector

OIP3 +40 dBm

Gain +12 dB

Output max power +27 dBm (0.5 W)

Impedance 50 Ohms

Power requirements 115V or 230V AC adaptor 12V DC, 500mA

Dimensions (D x W x H) 205 x 215 x 44 (mm)

Weight 1.2 Kg
